Touch & display all in one embedded solution: combining ITO touch screens with liquid crystal displays. Different thick strengthened (tempered or chemically) cover glass with/without anti-glare treatment makes them well suited for deployment in a wide variety of commercial and industrial environments.
With a evolution ITO touch panel and chip-on-board (COB) touch controller bonded to a commercial or Industrial grade LCD, All touch LCM display modules deliver reliability that help streamline your supply chain and simplify assembly.
Optically bonded touch display modules widely used for indoor touch terminal devices, such as conference ,education, intelligent blackboard, leisure and entertainment, vending machines.
| Part Number(s) | GDT156PCT-G156HAN4 |
| Construction | Glass-Glass-OCA-LCM |
| Touch Outline Dimensions | 403.8 mm x 254.5 mm |
| Cover Glass | 4mm tempered soda lime glass |
| Surface Treatment | Anti-Glare 80 ± 10GU |
| Light Transmittance | 88 ± 3% |
| Haze | <15% |
| Touch Controller Form Factor | COB |
| Touch Interface | USB |
| Touch Accuracy | +/- 2.5mm |
| Streaming Report Rate | >100Hz |
| Number of Touches | Multi Touch (Up to 10) |
| Touch Screen Operating Temp Range | -20°C to +70°C |
| LCD Diagonal | 15.6” |
| LCD Resolution | 1920 x 1080 |
| LCD Viewing Area | 346.1 mm x 195.4 mm |
| LCD Brightness | 1000 nits |
| LCD Backlight Life | 50,000 hours |
| LCD Viewing Angle | 160 degree horizontal and 178 degree vertical |
| LCD Operating Temp Range | -20°C to +60°C |
| LCD Interface | LVDS |
| Warranty | 1-years (2~3 years are as options) |
Sizes ranging from 3.5 to 32 inches are available in standard or custom options.
From design and engineering to prototyping and production, GDT create your touchscreen display modules following your requests.
1). LCDChoose: An open spaces is offered to customers on choose LCD. Customer can specify the LCD brands and models based off their needs. If open cell type LCD Panel used,information such as Resolution, Brightness, Temperature Range, Viewing Angle, Interface, are needed.
2). Touch SensorChoose: Touch sensor thick, FPC Tail position and size
3). Cover Glass Choose: Custom sizes, shapes, edge treatments, holes and cut-outs, materials (strengthened glass, safety glass, IR/UV blocking glass for outdoor) Anti-glare anti-fingerprinting Anti-reflective surface treatments, Border (colors, logos, icons, IR transmissive windows)
4). Touch ControllersChoose: Wide variety of touch IC’s. Performance tuning for water,gloves and touch keys, suitable for thick cover glass or overlays, other application specific tuning as requested.
5). Special DisplaysChoose: Screen peep-proof protection, Anti-blue light eye protection, IR blockers, UV filters.
6). Bonding Choose:Optical Bonding is prefered
Still mot sure how to design your touchscreen display modules? Please get touch with GDT sales ask for technical support and desgin .
