| Television Features | Support 20 touch points; Support image magnification, narrow, and rotation; Touch function is available when each signal source switch; Support display mode, the signal source by touch control signal source, such as the volume control menu. |
| Other Features | Sleep timer, shutdown memory; Support remote control instead of keyboard, realize F1-F2 button function, remote control TV power on function; Support to achieve the touch menu, return key, menu operation, tasks, preview, channel switch, volume adjustment, quick electroic whiteboard operation, etc. Support the system main page click on any one source; Support remote control child lock function; Support wireless wifi, LAN cable; Support front button one-key switch computer, TV; Support embedded high-definition camera to take pictures and record functions (requires option support); Front HDMI, USB 2.0, USB 3.0, Touch Interface, easy for users to use. |
System Parameters
| Processor | 8386CORTEX A53 1.8GHz |
| Operate System | Android 8.0 Embedded System |
| RAM | DDR3 2G |
| ROM | 16G |
| External storage | SD card can expand up to 128G, USB2.0/3.0 can support up to 1T |
Display Parameters
| Display Size | 55"/65"/75"/86" |
| Display type | Ultra HD DLED display |
| Active Area | / |
| Resolution | 3840(H)*2166(V) |
| Display Color | 10bit, 1.07B |
| Frequency | 60HZ |
| Brightness | 350cd/m2 |
| Contrast | 5000:1 |
| Viewing Angel | 178° |
| Display glass | 4.0mm Full toughened high explosion-proof glass |
| Backlight life | 50000 hours |
Touch Panel Parameters
| Touch embedding mode | Built-in integrated, non-external |
| Touch Panel Type | Infrared induction recognition touch technology(20 points) |
| Touch method | Finger, Touch Pens, Other non-transparent objects not less than 5mm in diameter(if multi-points,it should be 8mm) |
| The Mouse speed | 120 point/s |
| positioning accuracy | More than 90% of the Active area is ±2mm |
| Interface | USB |
| Max Resolution | 32767*32767 |
| Touch Lifetime | Theoretically infinite times |
| Touch response time | <=15ms |
| Driver | No need Driver |
| Infrared Touch | |||
| Product Name | Parameters | Functions | Remarks |
| Multi Touch Panel | Touch mode: Infrared InductionDrive mode: No Drive | Support less than or equal to the maximum touch points for independent writing, painting; Supports anti-occlusion function. | / |
| Camera | |||
| Product Name | Parameters | Functions | Remarks |
| Camera | Pixel: 500w | HD Camera take photos and videos | / |
| Tempered Glass | |||
| Product Name | Parameters | Functions | Remarks |
| Anti-Glare Glass | Tempered Glass in AG | Anti-Glare | / |
| Computer Configuration Option 1 (Cops Solution) | ||||
| Medium Configuration(i3) | High Configuration(i5) | Top Configuration(i7) | ||
| Chip Set | Intel Chip | |||
| CPU | Inter Core i3 | Inter Core i5 | Inter Core i7 | |
| Storage | 4G DDR3 Memory/2.5 inch 500G Hard Disk | 4G DDR3 Memory/2.5 inch 500G Hard Disk | 4G DDR3 Memory/2.5 inch 500G Hard Disk | |
| Display Board | Intel HD Graphics | Intel HD Graphics | Intel HD Graphics | |
| Interface | USB 2.0 *4, USB 3.0 *2,RJ45 Network interface * 1,MIC in*1,HDMI out*1,VGA out*1Line out*1,Support Wifi 802.11b/g/n | |||
| Operation System | Windows 7 flagship version Operation System | |||
| Computer Configuration Option 2 (OPS Solution) | ||||
| Medium Configuration(i3) | High Configuration(i5) | Top Configuration(i7) | ||
| Chip Set | Intel Chip | |||
| CPU | Inter Core i3 | Inter Core i5 | Inter Core i7 | |
| Storage | 4G DDR3 Memory/2.5 inch 500G Hard Disk | 4G DDR3 Memory/2.5 inch 500G Hard Disk | 4G DDR3 Memory/2.5 inch 500G Hard Disk | |
| Display Board | Intel HD Graphics | Intel HD Graphics | Intel HD Graphics | |
| Interface | USB 2.0 *2USB 3.0 *2RJ45 Network interface * 1HDMI*1Line out*1MIC in*1Support Wifi | |||
| Operation System | Windows 7 flagship version Operation System | |||
Touch Screen Dimensions
